Boyee - China Full Ceramics Bead Mill Machine, Sand Mill Manufacturer & Supplier

Hotbead Grinder 58 BOYEE Brand 1
Hotbead Grinder 58 BOYEE Brand 2
Hotbead Grinder 58 BOYEE Brand 3
Hotbead Grinder 58 BOYEE Brand 1
Hotbead Grinder 58 BOYEE Brand 2
Hotbead Grinder 58 BOYEE Brand 3

Hotbead Grinder 58 BOYEE Brand

Weight (kg):
2480
Speed (r/min):
0-776
Power (KW):
75
Volume (L):
58
Model:
NMM60L
Inquiry

Product Display

NMM-60L滤网 (2)
NMM-60L滤网 (2)
NMM-60L滤网 (3)
NMM-60L滤网 (3)
NMM-60L滤网
NMM-60L滤网
微信图片_20220906094608

Product Description

Boyee's patented TurboMax turbo and rod pin grinding systems effectively enhance grinding quality and precision, reduce cost of losses, and improve production efficiency.

Product Advantages

● Exceptional capability in handling high viscosity materials.

● Widely used in a variety of materials on the market

● Smooth material discharge without any blockages.

● Optional Boyee TurboMax patented turbo and rod pin grinding systems

● Ceramic, polymer and alloy components are available

微信图片_20230207155218

Product Parameters

Model Volume (L) Power (KW) Speed (r/min) Mediadiameter (mm) Weight (kg) Size (mm)
NMM-3L 3 7.5 0-1450 ≥0.2 800 1400×1100×1680
NMM-10L 10 18.5 0-1460 ≥0.2 1280 1800×1200×1550
NMM-30L 30 45 0-1000 ≥0.2 1850 1800×1300×1800
NMM-60L 58 75 0-776 ≥0.2 2480 3290×1478×1950
NMM-90L 98 75-90 0-776 ≥0.2 3050 3290×1478×1950
NMM-150L 120-180 160 0-627 ≥0.2 5280 4500×1700×2400
NMM-400L 400 280-315 0-460 ≥0.2 8600 4600×1600×2400

Product Features

Boyee's patented TurboMax turbo and rod pin grinding systems effectively enhance grinding quality and precision, reduce cost of losses, and improve production efficiency.

Product Application

化工
Chemical industry
MLCC
MLCC
打印油墨 (2)
Printing ink
未标题-1
Battery
未标题-2
Cosmetics
医药
Medicine

Faqs

How to choose the right size and weight of zirconium beads?

Choosing the right size and weight of zirconium beads for your bead mill will depend on several factors, including the material being milled, the desired particle size distribution, and the milling conditions. Here are some general guidelines:


Material being milled: The hardness and density of the material being milled can impact the size and weight of the beads needed. Harder and denser materials may require larger and heavier beads to effectively break down the particles.


Desired particle size: The size of the beads will impact the final particle size distribution. Smaller beads can result in finer particle size distributions, while larger beads may produce coarser particles.


Milling conditions: The speed and intensity of the milling process can also impact the size and weight of the beads needed. Higher milling speeds or longer milling times may require larger and heavier beads to maintain the desired milling intensity.


Bead-to-material ratio: The ratio of beads to material in the milling chamber can also impact the size and weight of the beads needed. Higher bead-to-material ratios may require larger and heavier beads to maintain efficient milling.


Equipment limitations: The size and weight of the beads should also be compatible with the equipment being used. Check the manufacturer's recommendations for the maximum size and weight of beads that can be used in your specific bead mill.


Chemical compatibility: Zirconium beads are highly resistant to corrosion, but it's still important to ensure that the beads are chemically compatible with the material being milled. Some materials may react with the zirconium, which can result in contamination of the final product.


Bead shape: In addition to size and weight, the shape of the beads can also impact the milling process. Cylindrical or spherical beads are the most common shapes, but there are also conical, tri-lobed, and other specialized shapes available. The shape of the beads can impact the flow dynamics within the milling chamber, which can affect the efficiency of the milling process.


Bead quality: The quality of the beads can also impact the milling process and the final product. Look for beads that are uniform in size and shape, and free from defects or irregularities.


Cost: The cost of the beads can vary depending on the size, weight, and quality. Consider the cost of the beads relative to the cost of the material being milled, as well as the potential impact on the final product.


In general, zirconium beads are available in a range of sizes from 0.1 mm to several millimeters in diameter, and weights can vary depending on the specific bead size and material composition. Consult with the bead manufacturer or supplier for specific recommendations based on your application and equipment.


Company Advantages

· BOYEE (SHENZHEN) INDUSTRIAL TECHNOLOGY CO., LTD's raw materials actively comply with international green specifications and customer requirements.

· The product is given a longer service time by our dedicated R&D team.

· With promising development prospects in the field, the product is widely used.


Company Features

· With a focus on bead grinder, BOYEE (SHENZHEN) INDUSTRIAL TECHNOLOGY CO., LTD is the world-renowned manufacturer.

· With a view to reaching advanced technological level, BOYEE (SHENZHEN) INDUSTRIAL TECHNOLOGY CO., LTD has introduced internationally advanced technology.

· BOYEE upholds the attitude of customer first. Get more info!


Application of the Product

The bead grinder produced by BOYEE is of high quality. And it is one of the products widely used in the industry.

Our solutions are developed by understanding the customer's situation and combining the current market conditions. Therefore, they are all targeted and can effectively solve problems of customers.

Contact us
we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
